5 Year Electrical, 5 Year Water, Lifetime Mechanical Warranty
THE LIGHTEST WINCHES IN THE WORLD
Carbon Offroad
Carbon 12K - 12000lb Winch With Black Hook V3
$1,099.00
Carbon Winch 12k 12000lb Electric 12v 4x4 WinchVersion 3 2023 Model - Now IP68 Waterproof5 Year Australian WarrantyLightest 4x4 Winch
Due to strong customer demand the Carbon Winch range has gone ALL BLACK.
If you ask us nicely, we will also change out the black hook for the colour of your choice (has to be in stock) at or before the time of dispatch only.
The all new feature packed Ver 3 12000lb Winch from Carbon Offroad delivers a 4wd winch package boasting many extras to make the installation and use of your winch that much easier.
The Carbon Winch features a newly upgraded rating of IP68, so your river crossings and mud runs are stress free, featuring a breathable membrane style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.
IP68 meaning - Ingress Protection6 - Can withstand dust and dirt8 - Can be submerged under freshwater for 30 minutes up to 1.5m depth, but not during operation.
You want the reliability of a winch that will perform when you need it to, time after time.
The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.
If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.
Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor . Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 19.0kg
Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.
Get a winch you can trust - Get a Carbon Winch
Carbon Offroad
Carbon 12K - 12000lb Winch With Red Hook V3
$1,099.00
Carbon Winch 12k 12000lb Electric 12v 4x4 WinchVersion 3 2023 Model - Now IP68 Waterproof5 Year Australian WarrantyLightest 4x4 Winch
Due to strong customer demand the Carbon Winch range has gone ALL BLACK.
If you ask us nicely, we will also change out the black hook for the colour of your choice (has to be in stock) at or before the time of dispatch only.
The all new feature packed Ver 3 12000lb Winch from Carbon Offroad delivers a 4wd winch package boasting many extras to make the installation and use of your winch that much easier.
The Carbon Winch features a newly upgraded rating of IP68, so your river crossings and mud runs are stress free, featuring a breathable membrane style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.
IP68 meaning - Ingress Protection6 - Can withstand dust and dirt8 - Can be submerged under freshwater for 30 minutes up to 1.5m depth, but not during operation.
You want the reliability of a winch that will perform when you need it to, time after time.
The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.
If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.
Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor . Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 19.0kg
Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.
Get a winch you can trust - Get a Carbon Winch
Carbon Offroad
Carbon 12K - 12000lb Winch With Orange Hook V3
$1,099.00
Carbon Winch 12k 12000lb Electric 12v 4x4 WinchVersion 3 2023 Model - Now IP68 Waterproof5 Year Australian WarrantyLightest 4x4 Winch
Due to strong customer demand the Carbon Winch range has gone ALL BLACK.
If you ask us nicely, we will also change out the black hook for the colour of your choice (has to be in stock) at or before the time of dispatch only.
The all new feature packed Ver 3 12000lb Winch from Carbon Offroad delivers a 4wd winch package boasting many extras to make the installation and use of your winch that much easier.
The Carbon Winch features a newly upgraded rating of IP68, so your river crossings and mud runs are stress free, featuring a breathable membrane style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.
IP68 meaning - Ingress Protection6 - Can withstand dust and dirt8 - Can be submerged under freshwater for 30 minutes up to 1.5m depth, but not during operation.
You want the reliability of a winch that will perform when you need it to, time after time.
The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.
If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.
Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor . Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 19.0kg
Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.
Get a winch you can trust - Get a Carbon Winch
Carbon Offroad
Carbon 12K - 12000lb Winch With Green Hook V3
$1,099.00
Carbon Winch 12k 12000lb Electric 12v 4x4 WinchVersion 3 2023 Model - Now IP68 Waterproof5 Year Australian WarrantyLightest 4x4 Winch
Due to strong customer demand the Carbon Winch range has gone ALL BLACK.
If you ask us nicely, we will also change out the black hook for the colour of your choice (has to be in stock) at or before the time of dispatch only.
The all new feature packed Ver 3 12000lb Winch from Carbon Offroad delivers a 4wd winch package boasting many extras to make the installation and use of your winch that much easier.
The Carbon Winch features a newly upgraded rating of IP68, so your river crossings and mud runs are stress free, featuring a breathable membrane style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.
IP68 meaning - Ingress Protection6 - Can withstand dust and dirt8 - Can be submerged under freshwater for 30 minutes up to 1.5m depth, but not during operation.
You want the reliability of a winch that will perform when you need it to, time after time.
The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.
If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.
Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor . Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 19.0kg
Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.
Get a winch you can trust - Get a Carbon Winch
Engineered for Excellence in Every Full
EXTREME PERFORMANCE
Carbon Offroad
Carbon Scout Pro - 15000lb Winch V3
$1,399.00
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets compared to our CW-12K, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
Did you Know: "Module" is the unit of size that indicates how big or small a gear is. It is the ratio of the reference diameter of the gear divided by the number of teeth.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 15000lb winch comes with 11mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
Carbon Winch 2023 V3 winch chassis
7.0HP Motor
218:1 heavy duty performance gearbox
11mm Synthetic Rope with HD braced rope thimble
Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Carbon Offroad MEGAPRO Winch Hook
High performance heavy duty upgraded solenoid unit, the solenoid in this winch is rated to 100amps more than the CW-12K solenoid unit.
Installed weight of 26.7kg
CW-XD15
12V DC performance specs (first layer of drum)
Line Pull
Line Speed
Motor
Pull by layer
Lbs.(Kgs.)
FT./min(M/min.)
Current
layer/Lbs(Kgs.)
0
27.9(8.5)
65 amps
1/15,000 (6810)
2000 (910)
11.8(3.6)
120 amps
2/12,700(5765)
6000 (2720)
9.5(2.9)
160 amps
3/10,770 (4890)
10000 (4540)
6.6 (2.0)
215 amps
4/9,130(4145)
13000 (5900)
4.6 (1.4)
265 amps
15000 (6818)
3.6 (1.1)
380 amps
Carbon Offroad
Carbon Scout Pro - 12000lb Winch With Black Hook V3
$1,349.00
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 12000lb winch comes with 11mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
Carbon Winch 2023 V3 winch chassis
7.0HP Motor
180:1 heavy duty performance gearbox
11mm Synthetic Rope with HD braced rope thimble
Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Carbon Offroad MEGAPRO 16 tonne soft shackle compatible winch rope thimble
High performance heavy duty upgraded solenoid unit
Installed weight of 26.7kg
CW-XD12
12V DC performance specs (first layer of drum)
Line Pull
Line Speed
Motor
Pull by layer
Lbs.(Kgs.)
FT./min(M/min.)
Current
layer/Lbs(Kgs.)
0
43.3 (13.2)
70 amps
1/12,000 (5450)
2000 (910)
14.8 (4.5)
115 amps
2/9800 (4450)
4000 (1810)
12.8 (3.9)
165 amps
3/8300 (3770)
6000 (2720)
9.2 (2.8)
215 amps
4/7200 (3270
10000 (4540)
7.5(2.3)
310 amps
12000 (5450)
5.6(1.7)
370 amps
Carbon Offroad
Carbon Scout Pro - 9000lb Winch V3
$1,329.00
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 9000lb winch comes with 10mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
Carbon Winch 2023 V3 winch chassis
7.0HP Motor
104:1 heavy duty performance gearbox
10mm Synthetic Rope with HD braced rope thimble
Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Carbon Offroad MEGAPRO 16 tonne soft shackle compatible winch rope thimble
High performance heavy duty upgraded solenoid unit, the solenoid in this winch is rated to 100amps more than the CW-12K solenoid unit.
CW-XD9
12V DC performance specs (first layer of drum)
Line Pull
Line Speed
Motor
Pull by layer
Lbs.(Kgs.)
FT./min(M/min.)
Current
layer/Lbs(Kgs.)
0
62.3(19)
80 amps
1/9,000 (4090)
2000 (910)
17.4(5.3)
150 amps
2/7,625 (3,460)
4000 (1810)
15.1(4.6)
220 amps
3/6,460 (2930)
6000 (2720)
13.4(4.1)
280 amps
4/5,480 (2,490)
8000 (3630)
11.5(3.5)
350 amps
9000 (4090)
10.5(3.2)
380 amps
Carbon Offroad
Carbon Scout Pro - 9000lb Winch V2
$1,329.00
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets compared to our CW-12K, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
Did you Know: "Module" is the unit of size that indicates how big or small a gear is. It is the ratio of the reference diameter of the gear divided by the number of teeth.
The Scout Pro series winches share the same 2021 Version 2 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 9000lb winch comes with 10mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
Carbon Winch 2023 V3 winch chassis
7.0HP Motor
104:1 heavy duty performance gearbox
10mm Synthetic Rope with HD braced rope thimble
Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Carbon Offroad MEGAPRO Winch Hook
High performance heavy duty upgraded solenoid unit, the solenoid in this winch is rated to 100amps more than the CW-12K solenoid unit.
Installed weight of 26.7kg
CW-XD9
12V DC performance specs (first layer of drum)
Line Pull
Line Speed
Motor
Pull by layer
Lbs.(Kgs.)
FT./min(M/min.)
Current
layer/Lbs(Kgs.)
0
62.3(19)
80 amps
1/9,000 (4090)
2000 (910)
17.4(5.3)
150 amps
2/7,625 (3,460)
4000 (1810)
15.1(4.6)
220 amps
3/6,460 (2930)
6000 (2720)
13.4(4.1)
280 amps
4/5,480 (2,490)
8000 (3630)
11.5(3.5)
350 amps
9000 (4090)
10.5(3.2)
380 amps
Like a TANK
INDESTRUCTIBLE, BULLETPROOF, POWERFUL
Carbon Offroad
Carbon TANK - 15000lb Winch 12V
$1,599.00
The Carbon Offroad TANK 15000lb electric winch is a force to be reckoned with.
A new generation of winches joins the Carbon Offroad offer. TANK is synonymous for indestructible, bulletproof and powerful, which is just what this winch is. TANK is also associated with heavy, which is something this winch is not!
We understand that building the ultimate offroad rig often requires a lot of time, effort and additional parts once it comes off the factory floor, and this all adds weight. The capability to self recover a vehicle is generally high on the list of priorities for most overlanding and touring journey people, as most of the time, solo travel is the reality. In the past, this generally required a winch with steel cable and a heavy steel bullbar to carry it, but in todays market, there are smarter options and this includes the winches. Yes you can still buy a cheap heavy winch made from castings of solid steel if you like that sort of thing, but technology has improved, materials have improved and this has led to a winch being designed and built like the TANK. Billet alloys machined on CNC mills, Alloy castings make up the gearbox housings and main frames of the winch, critical components such as the winch drum are still made from steel, but this winch also features an aesthetic quality that is almost unmatched in the market. If you truly appreciate good design, the TANK will impress with it's sexy lines, solid cast alloy control box and solid alloy fairlead.
One of the most notable requirements of modern winches is that a winch must be waterproof. The TANK winch features a system unseen before in the winch market. The winch motor and drum frame mount are assembled as one unit at the factory, then it undergoes real life pressure leak testing to 20PSI on a custom made jig specially designed for this test, simulating the same pressure as a depth of 14 metres underwater! It must pass this test before moving further down the assembly line. We guarantee this winch will not see water out of the box.
Aside from the motor side, the gearbox housing also features a two stage mechanical and rubber o-ring sealing system which will ensure that part of the winch is also 100% sealed from water ingress to IP69K levels.
Other functions of the winch remain similar to our other winches, utilising a rotating ring gear free spool clutch assembly, 3 stage planetary gear train made from solid cut and hardened gear steel, with the gear train being oversize and similar to our Scout Pro Extreme Duty winches. It also features a gear train connected braking system which mitigates any heat build up on the drum which could cause damage to the winch rope.
The control box can be mounted over the drum directly into the threaded holes in the tie bars or over the motor with supplied mounting brackets, it can also be mounted remotely flush onto a bar or there is an optional remote mounting bracket available separately.
What is in the box:
1 x Tank winch with synthetic rope
1 x control box kit complete with cables
1 x battery earth cable
1 x 2 in 1 wireless remote control with plug in cable backup
1 x Alloy fairlead - standard offset
1 x Forged Alloy hook with mounting pin and split pin
1 x Mounting Bolt kit including separate fairlead mounting bolts
1 x control box "over motor" mounting bracket pair
1 x bolt kit for control box mounting
1 x rotary battery isolator switch
1 x battery isolator connecting cable 30cm
1 x battery isolator mounting bracket
1 x hook safety strap
1 x instruction manual
Specifications:
Rated Pulling Power: 15000lb (6804kg)
Power: 12V DC
Motor: 7.2HP Series Wound intermittent duty cycle
Cabling: 25mm2 conduited cable with terminated lugs
Hand Control: 2 in 1 rechargeable wireless or plug in wired loom -(spare battery included)
IP Rating: IP68 - Motor unit pressure tested to 20psi
Hook: High strength forged alloy wide gate hook
Control box: Premium Cast alloy compact design for over motor or over drum fitment with 600amp solenoid and inbuilt wireless receiver.
Isolator: Heavy duty marine rotary style isolator with mounting bracket
Winch Housing: Cast and precision machined alloy
Gear Train: 234:1 Ratio 3 stage planetary gearset
Clutch: Rotating ring gear clutch - easy engagement and disengagement
Synthetic rope: 26mm of 10mm diameter UHMWPE fibre
Mounting bolt pattern: industry standard 254mm x 114.3mm (10 x 4.5 inch)
Drum Diameter: 64mm
Battery: 650CCA minimum vehicle battery size for winching.
Weight:
Shipping Carton Weight: 29.5KG
As fitted to vehicle: 26.2kg
Rated Line Pull:
1st layer of drum: 15000lb (6804kg) / Between 20-25m rope out
2nd layer of drum: 12386lb (5618kg) / Between 9-20m rope out
3rd layer of drum: 9184lb (4166kg) / Between 1-9m rope out
Line pull 0kg
Speed: 16.4ft/min - 5m/min
Amp Draw: 85 amp
Line pull 3750lb / 1361kg
Speed: 10.5ft/min - 3.2m/min
Amp Draw: 152 amp
Line pull 7500lb / 2722kg
Speed: 8.2ft/min - 2.5m/min
Amp Draw: 239 amp
Line pull 11250lb / 4082kg
Speed: 5.24ft/min - 1.6m/min
Amp Draw: 249 amp
Line pull 15000lb / 5443kg
Speed: 3.93ft/min - 1.2m/min
Amp Draw: 422 amp
Warranty
Limited Lifetime Geartrain / 5 Year Electrical.
5 Year Water Ingress Protection Warranty
Carbon Offroad
Carbon TANK - 12000lb Winch 12V
$1,499.00
The Carbon Offroad TANK 12000lb electric winch is a force to be reckoned with.
A new generation of winches joins the Carbon Offroad offer. TANK is synonymous for indestructible, bulletproof and powerful, which is just what this winch is. TANK is also associated with heavy, which is something this winch is not!
We understand that building the ultimate offroad rig often requires a lot of time, effort and additional parts once it comes off the factory floor, and this all adds weight. The capability to self recover a vehicle is generally high on the list of priorities for most overlanding and touring journey people, as most of the time, solo travel is the reality. In the past, this generally required a winch with steel cable and a heavy steel bullbar to carry it, but in todays market, there are smarter options and this includes the winches. Yes you can still buy a cheap heavy winch made from castings of solid steel if you like that sort of thing, but technology has improved, materials have improved and this has led to a winch being designed and built like the TANK. Billet alloys machined on CNC mills, Alloy castings make up the gearbox housings and main frames of the winch, critical components such as the winch drum are still made from steel, but this winch also features an aesthetic quality that is almost unmatched in the market. If you truly appreciate good design, the TANK will impress with it's sexy lines, solid cast alloy control box and solid alloy fairlead.
One of the most notable requirements of modern winches is that a winch must be waterproof. The TANK winch features a system unseen before in the winch market. The winch motor and drum frame mount are assembled as one unit at the factory, then it undergoes real life pressure leak testing to 20PSI on a custom made jig specially designed for this test, simulating the same pressure as a depth of 14 metres underwater! It must pass this test before moving further down the assembly line. We guarantee this winch will not see water out of the box.
Aside from the motor side, the gearbox housing also features a two stage mechanical and rubber o-ring sealing system which will ensure that part of the winch is also 100% sealed from water ingress to IP69K levels.
Other functions of the winch remain similar to our other winches, utilising a rotating ring gear free spool clutch assembly, 3 stage planetary gear train made from solid cut and hardened gear steel, with the gear train being oversize and similar to our Scout Pro Extreme Duty winches. It also features a gear train connected braking system which mitigates any heat build up on the drum which could cause damage to the winch rope.
The control box can be mounted over the drum directly into the threaded holes in the tie bars or over the motor with supplied mounting brackets, it can also be mounted remotely flush onto a bar or there is an optional remote mounting bracket available separately.
What is in the box:
1 x Tank winch with synthetic rope
1 x control box kit complete with cables
1 x battery earth cable
1 x 2 in 1 wireless remote control with plug in cable backup
1 x Alloy fairlead - standard offset
1 x Forged Alloy hook with mounting pin and split pin
1 x Mounting Bolt kit including separate fairlead mounting bolts
1 x control box "over motor" mounting bracket pair
1 x bolt kit for control box mounting
1 x rotary battery isolator switch
1 x battery isolator connecting cable 30cm
1 x battery isolator mounting bracket
1 x hook safety strap
1 x instruction manual
Specifications:
Rated Pulling Power: 12000lb (5454kg)
Power: 12V DC
Motor: 7.0HP Series Wound intermittent duty cycle
Cabling: 25mm2 conduited cable with terminated lugs
Hand Control: 2 in 1 rechargeable wireless or plug in wired loom -(spare battery included)
IP Rating: IP68 - Motor unit pressure tested to 20psi
Hook: High strength forged alloy wide gate hook
Control box: Premium Cast alloy compact design for over motor or over drum fitment with 600amp solenoid and inbuilt wireless receiver.
Isolator: Heavy duty marine rotary style isolator with mounting bracket
Winch Housing: Cast and precision machined alloy
Gear Train: 234:1 Ratio 3 stage planetary gearset
Clutch: Rotating ring gear clutch - easy engagement and disengagement
Synthetic rope: 26m of 10mm diameter UHMWPE fibre
Mounting bolt pattern: industry standard 254mm x 114.3mm (10 x 4.5 inch)
Drum Diameter: 64mm
Battery: 650CCA minimum vehicle battery size for winching.
Weight:
Shipping Carton Weight: 29.5KG
As fitted to vehicle: 26.2kg
Rated Line Pull:
1st layer of drum: 12000lb (5443kg) / Between 20-25m rope out
2nd layer of drum: 9210lb (4186kg) / Between 9-20m rope out
3rd layer of drum: 6894lb (3127kg) / Between 1-9m rope out
Line pull 0kg
Speed: 16.4ft/min - 5m/min
Amp Draw: 85 amp
Line pull 3000lb / 1361kg
Speed: 9.75ft/min - 3m/min
Amp Draw: 137 amp
Line pull 6000lb / 2722kg
Speed: 7.5ft/min - 2.28m/min
Amp Draw: 191 amp
Line pull 9000lb / 4082kg
Speed: 5.76ft/min - 1.76m/min
Amp Draw: 249 amp
Line pull 12000lb / 5443kg
Speed: 4.88ft/min - 1.49m/min
Amp Draw: 300 amp
Warranty
Limited Lifetime Geartrain / 5 Year Electrical.
5 Year Water Ingress Protection Warranty
5 Year Water Ingress Protection Warranty
Carbon Offroad
Carbon TANK - 20000lb Winch 12V
$2,399.00
The Carbon Offroad TANK 20000lb electric winch is a force to be reckoned with.
A new generation of winches joins the Carbon Offroad line up. TANK is synonymous for indestructible, bulletproof and powerful, which is just what this winch is. TANK is also associated with heavy, which is something this winch is not!
We understand that building the ultimate offroad rig often requires a lot of time, effort and additional parts once it comes off the factory floor, and this all adds weight. The capability to self recover a vehicle is generally high on the list of priorities for most overlanding and touring journey people, as most of the time, solo travel is the reality. In the past, this generally required a winch with steel cable and a heavy steel bullbar to carry it, but in todays market, there are smarter options and this includes the winches. Yes you can still buy a cheap heavy winch made from castings of solid steel if you like that sort of thing, but technology has improved, materials have improved and this has led to a winch being designed and built like the TANK. Billet alloys machined on CNC mills, alloy castings make up the gearbox housings and main frames of the winch, critical components such as the winch drum are still made from steel, but this winch also features an aesthetic quality that is almost unmatched in the market. If you truly appreciate good design, the TANK will impress with it's sexy lines, solid cast alloy control box and solid alloy fairlead.
One of the most notable requirements of modern winches is that a winch must be waterproof. The TANK winch features a system unseen before in the winch market. The winch motor and drum frame mount are assembled as one unit at the factory, then it undergoes real life pressure leak testing to 20PSI on a custom made jig specially designed for this test, simulating the same pressure as a depth of 14 metres underwater! It must pass this test before moving further down the assembly line. We guarantee this winch will not see water out of the box.
Aside from the motor side, the gearbox housing also features a two stage mechanical and rubber o-ring sealing system which will ensure that part of the winch is also 100% sealed from water ingress to IP69K levels.
Other functions of the winch remain similar to our other winches, utilising a rotating ring gear free spool clutch assembly, 4 stage planetary gear train made from solid cut and hardened gear steel, with the gear train being oversize and similar to our Scout Pro Extreme Duty winches. It also features a gear train connected braking system which mitigates any heat build up on the drum which could cause damage to the winch rope.
The control box can be mounted over the drum directly into the threaded holes in the tie bars or over the motor with supplied mounting brackets, it can also be mounted remotely flush onto a bar or there is an optional remote mounting bracket available separately.
The Tank 20000lb come in both 12 volt and 24 volt configurations allowing fitment on large 4x4s through to trucks running 24 volt systems. With a single line pull capacity over 9 tonne, you can be sure this winch will perform when no other option exists to extract your vehicle from a sticky situation.
What is in the box:
1 x Tank winch with synthetic rope
1 x control box kit complete with cables
1 x battery earth cable
1 x 2 in 1 wireless remote control with plug in cable backup
1 x Alloy fairlead - standard offset
1 x Forged Alloy hook with mounting pin and split pin
1 x Mounting Bolt kit including separate fairlead mounting bolts
1 x control box "over motor" mounting bracket pair
1 x bolt kit for control box mounting
1 x rotary battery isolator switch
1 x battery isolator connecting cable 30cm
1 x battery isolator mounting bracket
1 x hook safety strap
1 x instruction manual
Specifications:
Rated Pulling Power: 20,000lb (9072kg)
Power: 12V DC or 24V DC (separate website listings)
Motor: 7.8HP Series Wound intermittent duty cycle
Cabling: 25mm2 conduited cable with terminated lugs
Hand Control: 2 in 1 rechargeable wireless or plug in wired loom -(spare battery included)
IP Rating: IP68 - Motor unit pressure tested to 20psi
Hook: High strength forged alloy wide gate hook
Control box: Premium Cast alloy compact design for over motor or over drum fitment with 600amp solenoid and inbuilt wireless receiver.
Isolator: Heavy duty marine rotary style isolator with mounting bracket
Winch Housing: Cast and precision machined alloy
Gear Train: 440:1 Ratio 4 stage planetary gearset
Clutch: Rotating ring gear clutch - easy engagement and disengagement
Synthetic rope: 21m of 14mm diameter UHMWPE fibre
Mounting bolt pattern: industry standard 254mm x 114.3mm (10 x 4.5 inch)
Drum Diameter: 88mm
Battery: 650CCA minimum vehicle battery size for winching.
Weight:
Shipping Carton Weight: 37KG
As fitted to vehicle: 33.4kg
Rated Line Pull:
1st layer of drum: 20000lb (9072kg) / Between 16-21m rope out
2nd layer of drum: 16216lb (7371kg) / Between 11-16m rope out
3rd layer of drum: 13636lb (6198kg) / Between 1-11m rope out
Line pull 0kg
Speed: 16.4ft/min - 5m/min
Amp Draw: 85 amp
Line pull 6000lb / 2721kg
Speed: 7.4ft/min - 2.25m/min
Amp Draw: 185 amp
Line pull 10000lb / 4563kg
Speed: 5.1ft/min - 1.55m/min
Amp Draw: 275 amp
Line pull 15000lb / 6803kg
Speed: 3.3ft/min - 1.0m/min
Amp Draw: 425 amp
Line pull 20000lb / 9072kg
Speed: 2.62ft/min - 0.8m/min
Amp Draw: 430 amp
Warranty is Limited Lifetime Geartrain / 5 Year Electrical. Designed for Australian and international conditions.
Carbon Offroad
Carbon TANK - 20000lb Winch 24V
$2,399.00
The Carbon Offroad TANK 20000lb electric winch is a force to be reckoned with.
A new generation of winches joins the Carbon Offroad line up. TANK is synonymous for indestructible, bulletproof and powerful, which is just what this winch is. TANK is also associated with heavy, which is something this winch is not!
We understand that building the ultimate offroad rig often requires a lot of time, effort and additional parts once it comes off the factory floor, and this all adds weight. The capability to self recover a vehicle is generally high on the list of priorities for most overlanding and touring journey people, as most of the time, solo travel is the reality. In the past, this generally required a winch with steel cable and a heavy steel bullbar to carry it, but in todays market, there are smarter options and this includes the winches. Yes you can still buy a cheap heavy winch made from castings of solid steel if you like that sort of thing, but technology has improved, materials have improved and this has led to a winch being designed and built like the TANK. Billet alloys machined on CNC mills, alloy castings make up the gearbox housings and main frames of the winch, critical components such as the winch drum are still made from steel, but this winch also features an aesthetic quality that is almost unmatched in the market. If you truly appreciate good design, the TANK will impress with it's sexy lines, solid cast alloy control box and solid alloy fairlead.
One of the most notable requirements of modern winches is that a winch must be waterproof. The TANK winch features a system unseen before in the winch market. The winch motor and drum frame mount are assembled as one unit at the factory, then it undergoes real life pressure leak testing to 20PSI on a custom made jig specially designed for this test, simulating the same pressure as a depth of 14 metres underwater! It must pass this test before moving further down the assembly line. We guarantee this winch will not see water out of the box.
Aside from the motor side, the gearbox housing also features a two stage mechanical and rubber o-ring sealing system which will ensure that part of the winch is also 100% sealed from water ingress to IP69K levels.
Other functions of the winch remain similar to our other winches, utilising a rotating ring gear free spool clutch assembly, 4 stage planetary gear train made from solid cut and hardened gear steel, with the gear train being oversize and similar to our Scout Pro Extreme Duty winches. It also features a gear train connected braking system which mitigates any heat build up on the drum which could cause damage to the winch rope.
The control box can be mounted over the drum directly into the threaded holes in the tie bars or over the motor with supplied mounting brackets, it can also be mounted remotely flush onto a bar or there is an optional remote mounting bracket available separately.
The Tank 20000lb come in both 12 volt and 24 volt configurations allowing fitment on large 4x4s through to trucks running 24 volt systems. With a single line pull capacity over 9 tonne, you can be sure this winch will perform when no other option exists to extract your vehicle from a sticky situation.
What is in the box:
1 x Tank winch with synthetic rope
1 x control box kit complete with cables
1 x battery earth cable
1 x 2 in 1 wireless remote control with plug in cable backup
1 x Alloy fairlead - standard offset
1 x Forged Alloy hook with mounting pin and split pin
1 x Mounting Bolt kit including separate fairlead mounting bolts
1 x control box "over motor" mounting bracket pair
1 x bolt kit for control box mounting
1 x rotary battery isolator switch
1 x battery isolator connecting cable 30cm
1 x battery isolator mounting bracket
1 x hook safety strap
1 x instruction manual
Specifications:
Rated Pulling Power: 20,000lb (9072kg)
Power: 12V DC or 24V DC (separate website listings)
Motor: 7.8HP Series Wound intermittent duty cycle
Cabling: 25mm2 conduited cable with terminated lugs
Hand Control: 2 in 1 rechargeable wireless or plug in wired loom -(spare battery included)
IP Rating: IP68 - Motor unit pressure tested to 20psi
Hook: High strength forged alloy wide gate hook
Control box: Premium Cast alloy compact design for over motor or over drum fitment with 600amp solenoid and inbuilt wireless receiver.
Isolator: Heavy duty marine rotary style isolator with mounting bracket
Winch Housing: Cast and precision machined alloy
Gear Train: 440:1 Ratio 4 stage planetary gearset
Clutch: Rotating ring gear clutch - easy engagement and disengagement
Synthetic rope: 21m of 14mm diameter UHMWPE fibre
Mounting bolt pattern: industry standard 254mm x 114.3mm (10 x 4.5 inch)
Drum Diameter: 88mm
Battery: 650CCA minimum vehicle battery size for winching.
Weight:
Shipping Carton Weight: 37KG
As fitted to vehicle: 33.4kg
Rated Line Pull:
1st layer of drum: 20000lb (9072kg) / Between 16-21m rope out
2nd layer of drum: 16216lb (7371kg) / Between 11-16m rope out
3rd layer of drum: 13636lb (6198kg) / Between 1-11m rope out
Line pull 0kg
Speed: 16.4ft/min - 5m/min
Amp Draw: 85 amp
Line pull 6000lb / 2721kg
Speed: 7.4ft/min - 2.25m/min
Amp Draw: 185 amp
Line pull 10000lb / 4563kg
Speed: 5.1ft/min - 1.55m/min
Amp Draw: 275 amp
Line pull 15000lb / 6803kg
Speed: 3.3ft/min - 1.0m/min
Amp Draw: 425 amp
Line pull 20000lb / 9072kg
Speed: 2.62ft/min - 0.8m/min
Amp Draw: 430 amp
Warranty is Limited Lifetime Geartrain / 5 Year Electrical. Designed for Australian and international conditions.
5 Year Water Ingress Protection Warranty
Don't stay stuck
GEAR TO GET YOU GOING
Carbon Offroad
2 x Carbon Gear Cube Storage and Recovery Bag Combo - Compact size
$69.96
Save $$$
Get 2 x Gear Cubes for a steal of a price!
Includes removeable internal sections
The Carbon Offroad Gear Cube recovery and storage bags are the ultimate in storage integration systems for various vehicle configurations.
Because they're designed so seamlessly they integrate into any vehicle configuration--whether you have drawer systems, canopy installations or simply throwing them into the footwell of your passenger seat.
These storage cubes also give you visibility over contents at all times thanks to their tinted clear top with a sturdy construction made from tough but lightweight vinyl where you can easily clean up spills and leaks from food,or mud and dirt from your recovery gear.
You can never be too prepared when you're on the road. Who knows what could happen and it's always good to have an extra bag or two for storage? The Carbon Offroad Gear Cube recovery and storage bags are designed with this in mind, allowing drivers of all sorts a way to store your gear without having it sit around loose in your vehicle which will inevitably get tossed about during any type of ride. These clever cubes come equipped with straps that allow you to secure them into place so there is no risk they'll fly out or otherwise lose their contents while being transported over rugged terrain. or simply slip into your drawers system or canopy build.
Gear Cube Features:
Compact Size: 40cm wide x 30cm long x 18cm high
Double layer 500 denier PVC waterproof canvas with EPDM sponge rubber internal structure which is a high-quality, closed-cell material that is commonly used to create an air and watertight seal, meaning this foam will never absorb water or lose it's structural properties. The bags maintain a very solid structure, even when loaded up, which means it's easier to handle when packing away or putting back into a vehicle.
Unique Carbon Camo pattern, a stylish and attractive pattern in shades of grey which allow it to blend into most vehicle interiors.
Bright orange zip unit allowing easy identification of the opening section in low light conditions, and easy to spot if you leave it lying on the side of the track
Black tinted PVC clear bag top. The black tint offers some additional security to prying eyes and provides a much better outcome against UV degradation of the material over time.
1.5 inch wide webbing straps allow secure carriage of the bags, we have tested the bags up to 20kg load with no failure on straps or stitching
Removeable Internal sections which allow organisation are secured with heavy-duty velcro, allowing you to seperate recovery or other items like steel d-shackles and snatch blocks from each other eliminating noise from steel on steel contact while out on the road. Two of these sections include heavy duty mesh zippered pockets for small items allowing sensible packing and easy access when required.
The bag straps can be lifted over the top of the bag allowing it to be dropped into a drawer system and then easily removed. The zipper can be accessed while the bag is packed inside a drawer unit.
Carbon Offroad
2 x Carbon Gear Cube Storage and Recovery Bag Combo - Large size
$90.96
$179.90
Save $$$
Get 2 x Gear Cubes for a steal of a price!
Includes removeable internal sections
The Carbon Offroad Gear Cube recovery and storage bags are the ultimate in storage integration systems for various vehicle configurations.
Because they're designed so seamlessly they integrate into any vehicle configuration--whether you have drawer systems, canopy installations or simply throwing them into the footwell of your passenger seat.
These storage cubes also give you visibility over contents at all times thanks to their tinted clear top with a sturdy construction made from tough but lightweight vinyl where you can easily clean up spills and leaks from food,or mud and dirt from your recovery gear.
You can never be too prepared when you're on the road. Who knows what could happen and it's always good to have an extra bag or two for storage? The Carbon Offroad Gear Cube recovery and storage bags are designed with this in mind, allowing drivers of all sorts a way to store your gear without having it sit around loose in your vehicle which will inevitably get tossed about during any type of ride. These clever cubes come equipped with straps that allow you to secure them into place so there is no risk they'll fly out or otherwise lose their contents while being transported over rugged terrain. or simply slip into your drawers system or canopy build.
Gear Cube Features:
Large Size: 50cm wide x 40cm long x 18cm high
Double layer 500 denier PVC waterproof canvas with EPDM sponge rubber internal structure which is a high-quality, closed-cell material that is commonly used to create an air and watertight seal, meaning this foam will never absorb water or lose it's structural properties. The bags maintain a very solid structure, even when loaded up, which means it's easier to handle when packing away or putting back into a vehicle.
Unique Carbon Camo pattern, a stylish and attractive pattern in shades of grey which allow it to blend into most vehicle interiors.
Bright orange zip unit allowing easy identification of the opening section in low light conditions, and easy to spot if you leave it lying on the side of the track
Black tinted PVC clear bag top. The black tint offers some additional security to prying eyes and provides a much better outcome against UV degradation of the material over time.
1.5 inch wide webbing straps allow secure carriage of the bags, we have tested the bags up to 20kg load with no failure on straps or stitching
Removeable Internal sections which allow organisation are secured with heavy-duty velcro, allowing you to seperate recovery or other items like steel d-shackles and snatch blocks from each other eliminating noise from steel on steel contact while out on the road. Two of these sections include heavy duty mesh zippered pockets for small items allowing sensible packing and easy access when required.
The bag straps can be lifted over the top of the bag allowing it to be dropped into a drawer system and then easily removed. The zipper can be accessed while the bag is packed inside a drawer unit.
Carbon Offroad
2 x Carbon Monkey Fist 13T Soft Shackle Combo Deal
$89.95
Get 2 x Carbon Offroad 13T Monkey Fist Soft Shackles
Buy more and save $$$$
The Carbon Offroad Monkey Fist Soft Shackle is an absolute winner!
The 10mm UHMWPE rope is rated at 13 tonnes minimum breaking strain and with a super heavy duty braided tight sheath over the core, this shackle is built to take some abuse.
Mininum Breaking Strain - 13209KG
The oversized Monkey Fist knot will ensure that there is Zero chance of the shackle ever coming apart during a recovery.
The braided heavy duty sheath allows you to go straight through a regular recovery point. Make sure it's in good nick though as the shackles can be damaged if the recovery point has nicks and burrs from previous use.
Easy disassembly of the shackle after load is applied is just as easy if not easier than a steel shackle.
You can use rope shackles for a number of uses:
Connecting your vehicle to a snatch strap or kinetic rope
Connecting a tree trunk protector strap to the winch hook
Connecting two straps together to extend your reach.
It also gives you further options like using it as an attachment point around a chassis rail or crossmember
Includes storage bag
Carbon Offroad
4 x Carbon Monkey Fist 13T Soft Shackle Combo Deal
$164.95
Get 4 x Carbon Offroad 13T Monkey Fist Soft Shackles
Buy more and save $$$$
The Carbon Offroad Monkey Fist Soft Shackle is an absolute winner!
The 10mm UHMWPE rope is rated at 13 tonnes minimum breaking strain and with a super heavy duty braided tight sheath over the core, this shackle is built to take some abuse.
Mininum Breaking Strain - 13209KG
The oversized Monkey Fist knot will ensure that there is Zero chance of the shackle ever coming apart during a recovery.
The braided heavy duty sheath allows you to go straight through a regular recovery point. Make sure it's in good nick though as the shackles can be damaged if the recovery point has nicks and burrs from previous use.
Easy disassembly of the shackle after load is applied is just as easy if not easier than a steel shackle.
You can use rope shackles for a number of uses:
Connecting your vehicle to a snatch strap or kinetic rope
Connecting a tree trunk protector strap to the winch hook
Connecting two straps together to extend your reach.
It also gives you further options like using it as an attachment point around a chassis rail or crossmember
Includes storage bag
Carbon Offroad
Carbon 20m 8T Winch Extension Strap and 2 x Bow Shackle Combo Deal
$99.95
Save $$$$
Get yourself a Carbon 20m Winch Extension Strap
and 2 x Bow Shackle Combo Deal.
This deal is an absolute bargain
Don't miss out!
Unreal value for money!
Kit Includes
1 x 20 metre x 8000kg - Carbon Winch Extension Strap
2 x 4.75T Bow Shackles
The Carbon Offroad Winch Extension Strap is an important winch accessory.
You've probably come across plenty of times where that tree or anchor is just a little bit too far away.
It's also handy to reduce the distance of an anchor if doing a double line pull.
Our winch extension being rated a minimum breaking strain of 8000kg is suitable for use with all of the winches in our Carbon Winch range, even the 17000lb truck winch.
8000kg Rating
20 metres long
UV resistant
Reinforced loops at both ends
multi-stitched ends
60mm wide
Made from high strength polyester
Want a tough bow shackle ?
Get the new Carbon 4.75 Ton Bow Shackle with anti-rattle insulators,
if you leave the shackles on your recovery points,
it stops them from chipping the paint off your expensive bullbar
and driving you insane with that annoying rattle.
Rated to 4.75 Tonne (working load Limit) WLL
Made from Strong C45 steel
Zinc plated then powder coated black for ultimate longevity.
19mm body
22mm pin
Powder coated black steel
2 x plastic washers
1 x plastic insulator
Carbon Offroad
Carbon 20m 8T Winch Extension Strap and 2 x Soft Shackle Combo Deal
$149.95
Save $$$$
Get yourself a Carbon Winch Extension Strap
and 2 x Soft Shackle Combo Deal.
This deal is an absolute bargain
Don't miss out!
Unreal value for money!
Kit Includes
1 x 20 metre x 8000kg - Carbon Winch Extension Strap
2 x 13,000kg Soft Shackles - Carbon Monkey Fist
2 x Soft Shackle Storage Bags
The Carbon Offroad Winch Extension Strap is an important winch accessory.
You've probably come across plenty of times where that tree or anchor is just a little bit too far away.
It's also handy to reduce the distance of an anchor if doing a double line pull.
Our winch extension being rated a minimum breaking strain of 8000kg is suitable for use with all of the winches in our Carbon Winch range, even the 17000lb truck winch.
8000kg Rating
20metres long
UV resistant
Reinforced loops at both ends
multi-stitched ends
60mm wide
Made from high strength polyester
Soft Shackle Information -
New Orange/Black Colour!!!!
The Carbon Offroad Monkey Fist Soft Shackle is an absolute winner! The 10mm UHMWPE rope is rated at 13 tonnes minimum breaking strain and with a super heavy duty braided tight sheath over the core, this shackle is built to take some abuse.
Mininum Breaking Strain - 13209KG
The oversized Monkey Fist knot will ensure that there is Zero chance of the shackle ever coming apart during a recovery.
The braided heavy duty sheath allows you to go straight through a regular recovery point. Make sure it's in good nick though as the shackles can be damaged if the recovery point has nicks and burrs from previous use.
Easy disassembly of the shackle after load is applied is just as easy if not easier than a steel shackle.
You can use rope shackles for a number of uses:
Connecting your vehicle to a snatch strap or kinetic rope
Connecting a tree trunk protector strap to the winch hook
Connecting two straps together to extend your reach.
It also gives you further options like using it as an attachment point around a chassis rail or crossmember
Includes storage bag
Carbon Offroad
Carbon 4.75 Ton Bow Shackle - New Upgraded
$14.95
Carbon 4.75 Ton Bow Shackle
* NOTE * : The latest shipmwent of these shackles have Green anti-rattle insulators in stead of Red
Multi Buy - The more you buy the more you save$$$
Want a tough bow shackle ?
Get the new Carbon 4.75 Ton Bow Shackle with anti-rattle insulators,
if you leave the shackles on your recovery points,
it stops them from chipping the paint off your expensive bullbar
and driving you insane with that annoying rattle.
Rated to 4.75 Tonne
Made from Strong C45 steel
Zinc plated then powder coated black for ultimate longevity.
19mm body
22mm pin
Powder coated black steel
2 x plastic washers
1 x plastic insulator
Carbon Offroad
Carbon 4m 14000kg Bridle Recovery Rope and 2 x Bow Shackle Combo Deal
$99.95
Save $$$$
Get yourself a Carbon 4m All Purpose Recovery Rope
and 2 x Bow Shackle Combo Deal.
This deal is an absolute bargain
Don't miss out!
Unreal value for money!
Kit Includes
1 x 4 metre x 14000kg - Carbon All Purpose Bridle Rope
2 x 4.75 Tonne Bow Shackles
The Monkey Fist All Purpose Recovery Rope. 4m x 16mm.
Manufactured with a UHMWPE core and thick braided sheath for great abrasion resistance
This rope is a short, tough and ultra handy recovery rope.
The eye splices offer 200mm length openings with a 32mm wide abrasion sheath
for long lasting protection on wear points.
4 metres long with dual protected eyelets with a minimum breaking strain of 14155kg.
Reach out to that winch anchor just out of reach, tow your mate, use as a bridle strap and more.
What can you do with it?
Here are just some examples:
Sling a rock or tree for an anchor or a pully for direction change to anchor
Use as a bridle strap between two front recovery points
Use as a short tow line
Use as a winch extension line
Carbon 4.75 Ton Bow Shackle
Want a tough bow shackle ?
Get the new Carbon 4.75 Ton Bow Shackle with anti-rattle insulators,
if you leave the shackles on your recovery points,
it stops them from chipping the paint off your expensive bullbar
and driving you insane with that annoying rattle.
Rated to 4.75 Tonne
Made from Strong C45 steel
Zinc plated then powder coated black for ultimate longevity.
19mm body
22mm pin
Powder coated black steel
2 x plastic washers
1 x plastic insulator
